Appendix A-5
Sensor Tests: Tests the functionality of sensors /switches/options by
manually toggling each sensor or installing an option.
Top Cover Swi t ch
Rear Cover Switch
Duplex Cover Switch
Stacker Cover Switch
Paper Tray Size Read (display paper size, for trays)
Print Cartridge Switch
Toner Sensor
Registration Sensor
Exit Sensor (Fuser)
Duplex Sensor
Stacker Sensor
Stacker Full Sensor
Output Tray Full Sensor
Tray 2 Low Paper
Tray 3 Low Paper
Tray 4 Low Paper
Tray 1 No Paper
Tray 2 No Paper
Tray 3 No Paper
Tray 4 No Paper
Duplex Unit Presence
Stacker Unit Presence
Solenoid Test: Tests the functionality of printer solenoids.
Stacker Direction Solenoid
Clutch Tests: Tests the functionality of printer Clutches.
Registration Roll
Tray 1 Feed
Tray 2 Feed
Tray 3 Feed
Tray 4 Feed
Tray 3 Tur n Roll
Tray 4 Tur n Roll
Controller NVRAM Access: This menu lets you reset the PS NVRAM locations to
factory defaults.
Reset PostScript NVRAM
Factory Reset NVRAM
Exit: Reboots Printer out of Diagnostics.
For Service Use Only The Service menu functions are to be used by Xerox
service personnel and authorized service providers. The
printer can be damaged by improper use of the built-in
service tests.
