Xerox PHASER 6121MFP User Manual

Troubleshooting
Phaser 6121MFP Multifunction Printer
User Guide
182
Remove original
in document feeder
The document is loaded in the auto
document feeder while a function is
set that requires scanning from the
document glass.
Remove the document from the auto
document feeder and place the
document on the document glass.
Results are over (xxx) The LDAP search results exceed the
maximum specified with Max.
Search Results in the LDAP Setting
menu.
Change the maximum setting, or
change the search conditions (for
example, increase the length of the
search word), and then try performing
the LDAP search again.
Reload (xxx) original
into document feeder
and press Start key
After a paper jam has been cleared
from the auto document feeder, the
number of document pages to be
reloaded into the auto document
feeder is indicated.
Reload into the auto document feeder
the number of document pages
indicated by (xxx) and then press the
Start button.
Memory full
at SMTP Server
The memory of the SMTP server has
become full.
Free up some space on the disk. If
necessary, contact your SMTP server
administrator.
Recipient memory is
full, cannot accept
fax or Email
The maximum number of 236
destinations for the scan data has
been reached.
Send the data and then try scanning
again. Otherwise, delete unnecessary
destinations before adding the desired
ones.
Toner l ife end
Replace (CMYK) toner
The indicated toner cartridge has
become empty.
Replace the indicated toner cartridge.
Toner empty
Replace (CMYK) toner
The indicated toner cartridge has
become empty. (This message
appears if Toner Out Action in the
General Setup menu is set to Stop
All.)
Toner Low (xx) The indicated toner cartridge is
nearly empty.
Prepare the indicated toner cartridge.
Tray 2 open
Close Tray 2
Tray 2 cassette is open. Close the tray by properly inserting and
seating the tray in the printer.
Toner Memory Error A memory error occurred in the
toner cartridge.
Re-install the specified toner cartridge.
USB Dev. Not support A USB device incompatible with this
printer is connected.
Disconnect the USB flash drive from this
printer and try a different USB device.
USB Hub Not support A USB hub is connected to this
printer.
This printer is not compatible with a
USB hub. When connecting USB cables
to this printer, do not use a USB hub.
USB memory full There is no space available on the
USB memory device connected to
this printer.
Delete data from the USB flash drive to
create free space, or use a different USB
flash drive.
Message Reason Action

Xerox PHASER 6121MFP Specifications

General

Print technology	Laser
Maximum resolution	1200 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	11 s
Time to first page (color, normal)	21 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Power supply type	AC
Dimensions (WxDxH)	405 x 427 x 375 mm
Printer management	MFP ControlCentre, Xerox CentreWare Internet Services, Xerox CentreWare Web
All-in-one functions	Copy, Scan
Standard media sizes	92 x 184mm - 216 x 356mm
Maximum internal memory	0.128 GB
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000/XP/Vista Mac OS X v10.3+
Scanner type	Flatbed scanner
Image formats supported	JPG
Maximum scan resolution	4800 x 4800 DPI
Copier resize	- %
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	45 s
Total input capacity	200 sheets
Total output capacity	100 sheets
Internal memory	128 MB
Card reader integrated	No
Sound pressure level (printing)	- dB
Display	LCD
Market positioning	Business
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 209 g/m²
Standard interfaces	USB 2.0
Power consumption (standby)	76 W
Power consumption (average operating)	271 W
Sustainability certificates	ENERGY STAR
Certification	EMC, FCC
Maximum duty cycle	35000 pages per month
Recommended duty cycle	1500 pages per month
Operating temperature (T-T)	10 - 35 °C
Non-operating relative humidity (non-condensing)	15 - 85 %
