4-56 WorkCentre C2424 Service Manual
_head Parked On?
Last Power Down?
Move Cap/Wiper
to the Park
ARMS- and restrain
head again.
8035,7009
Home Dmfix
7002
Jog the X
Axis in
order to
release the
Head Tilt
Arms.
Move Head to the
PARK position,
7007, 7008, 8005, 8055, 8007,
8008, 8009, 7014
If not in non-thermals
Oil Drum 4 times
DONE
Did the
Process Motor
Devise Fault?
Move Head to the
Standby position.
7007, 7008, 8005, 8055, 8007,
8008, 8009
Move XA to Left
Side Hard Stop
6000
Move XA to Tilt
Position
6000
Move Head to the
Home/ Print
position
7010
Start YA Slew
5003
Rehome XA
6000
RECOVERY ROUTINE
Try to recover from Process Motor Stall
Home XA
6000
Move XA to Left
Side Hard Stop
6000
Move XA to Tilt
Position
6000
home Dmfix
again
4025
Warmup is responsible for
moving the head to the print position
after the wipe and purge are
performed.
NO
YES
YES
YES
NO
NO
Device Fault Codes 80xx - Wiper 7002 - PM stalled 70xx - Headtilt 7014 - Head Not Restrained 31001 - Media Path 5001 - YA Home Timer 5002 YA - Encoder (Stall) 6000 - XA Error 4025 - PM Init Failed (home Dmfix) 4024 - Wiper Alignment Failed Others..... - Thermal Faults, ECM Faults, HC, PM Faults oiling drum
Jog the
X
Axis in order to release t
he
Head Til
t
Arms.
s2424-067
