10-9

Right-Side Wiring Diagram

The lines indicate which connectors you should look at for the Pest codes. The Pest

codes are displayed on the control panel.

Wiring Harnes

Pass-Through

Wiring Harness Pass-Through

37016.4x

HM Clutch

J680 13067.4x

J870 13067.4x

J860 Maintenanc

Kit Missing

J400 Drum Heater

600 Add Paper Tray

J250 37020.4x Strip Solenoid

J110 Waste Tray

Ground Clip

610 No Handfeed

J910 13387.4

J840 Dead

Power

37006.4x

rum Heater

5002.42

37014.4x Drum Fan

Paper Full Sensor

MEP Drive Motor

s2424-200
