Inside Top Wiring Diagram (continued)

The lines indicate which connectors you should look at for the Pest codes. The Pest

codes are displayed on the control panel.

s2424-206

Heater Cable

Cable Restraint

Out of Ink

J180 32064.4x

J140 37063.4x Head VPP

J110 37062.4x Head VSS
