Yamaha 200A - Page 63

60H5E11
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
60H40030
4-4
Fuel filter, fuel pump, fuel hose connector
No. Part name Q’ty Remarks
1 Bolt 1 M6 x 16 mm
2 Washer 1
3 Fuel filter nut holder 1
4 Bolt 1 M6 x 14 mm
5 Fuel filter bracket 1
6 Fuel filter cap 1
7 O-ring 1
8 O-ring 1
9 Fuel filter element 1
10 Spring 1
11 Red ring 1
12 Fuel filter cup 1
13 Fuel filter nut 1
14 O-ring 1
15 Drain screw 1
