Yamaha 200A - Power Unit Component Lists

60H5E11
Power unit
POWR
60H50020
5-3
1 Flywheel cover 1
2 Intake silencer 1
3 Screw 12 M5 x 55 mm
4 Bolt 2 M6 x 20 mm
5 Retaining plate 1
6 Grommet 1
7 Air vent hose 1
8 Dowel pin 2
9 Gasket 1
10 Bolt 2 M6 x 30 mm
11 Bolt 6 M8 x 135 mm
12 Bolt 2 M6 x 20 mm
13 Apron 1
14 Bolt 2 M6 x 20 mm
15 Bolt 2 M6 x 20 mm
16 Upper case cover 1
17 Bolt 4 M8 x 30 mm
No. Part name Q’ty Remarks
11
12
9
10
1
4
5
6
8
3
2
7
19
20
13
14
15
16
17
17
18
21
22
23
24
