Yamaha 200A - Page 78

60H5E11
Power unit
POWR
60H50030
1 Nut 1 : 30 mm
2 Washer 1
3 Flywheel magnet assembly 1
4 Bolt 3 M6 x 60 mm
5 Stator assembly 1
6 Pulser coil assembly 1
7 Screw 4 M6 x 18 mm
8 Stopper 4
9 Base 1
10 Timing plate 1
11 Screw 1 M6 x 10 mm
12 Woodruff key 1
No. Part name Q’ty Remarks
C
572
LT
E
1
2
3
4
5
6
8
9
10
11
7
12
5-5
