Yamaha 30D - Page 288

To Next Page

To Previous Page

7-28

BRKT

PUMP HOUSING

EXPLODED DIAGRAM

Step Procedure/Part name Q’ty Service points

19 Relief valve seat 1

20 O-ring 1 8.8 × 1.9 mm

21 O-ring 1 7.8 × 1.9 mm

22 Shuttle piston 1

23 O-ring 1 2.8 × 1.9 mm

Reverse the disassembly steps for instal-

lation.
