4-3
FUEL
E
FUEL SYSTEM
4. Using a soft brush and solvent, clean
the filter-cup thoroughly. Inspect the fil-
ter-cup for cracks or thread damage,
and replace if required.
5. Place the O-ring on the filter body,
install the element, and screw in the fil-
ter cup.
Fuel joints
1. Inspect the fuel joints for leaks and
cracks, and replace if required.
E22003-0
INSTALLATION
1. Referring to the diagram, install the fuel
system.
Note the following points:
●
When connecting the fuel hoses to
the fuel filter, follow the direction of
flow indicated by the embossed
arrows.
●
Place the clips in position, connect
the hoses, and tighten the clips.
Check for leaks.
