4-5
FUEL
E
CARBURETOR
E31000-0
REMOVAL AND DISASSEMBLY
WARNING
At this step, ensure there is no spillage of
gasoline (petrol) on removing the connec-
tions.
1. Remove the silencer cover, disconnect
the fuel hoses and links, then remove
the carburetor.
3. Using solvent, clean the components
thoroughly, and blow-dry them with
compressed air.
WARNING
Protect your eyes with suitable safety spec-
tacles or safety goggles when using com-
pressed air. Protect your eyes and the eyes
of other persons by directing the flow of
compressed-air downward, noting that sol-
vent and small parts may be blown off.
CAUTION:
Do not use steel wire for cleaning the jets
as this may enlarge the jet diameters and
seriously affect performance.
2. Referring to the diagram, use a screw-
driver to disassemble the carburetor.
