2.1 Ratings and Specifications
2.1.1 Ratings
2-2
2.1 Ratings and Specifications
This section gives the ratings and specifications of SERVOPACKs.
2.1.1 Ratings
Three-Phase, 200 VAC
* This is the net value at the rated load.
Single-Phase, 200 VAC
* This is the net value at the rated load.
Model SGD7S- R70A R90A 1R6A 2R8A 3R8A 5R5A 7R6A 120A 180A 200A
Maximum Applicable Motor Capacity
[kW]
0.05 0.1 0.2 0.4 0.5 0.75 1.0 1.5 2.0 3.0
Continuous Output Current [Arms] 0.66 0.91 1.6 2.8 3.8 5.5 7.6 11.6 18.5 19.6
Instantaneous Maximum Output Cur-
rent [Arms]
2.1 3.2 5.9 9.3 11 16.9 17 28 42 56
Main
Circuit
Power Supply 200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms]
*
0.4 0.8 1.3 2.5 3.0 4.1 5.7 7.3 10 15
Control Power Supply 200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Power Supply Capacity [kVA]
*
0.2 0.3 0.5 1.0 1.3 1.6 2.3 3.2 4.0 5.9
Power
Loss
*
Main Circuit Power Loss [W] 5.1 7.3 13.5 24.0 20.1 43.8 53.6 65.8 111.9 113.8
Control Circuit Power Loss
[W]
17 17 17 17 17 17 17 22 22 22
Built-in Regenerative Resis-
tor Power Loss [W]
−−−−888101616
Total Power Loss [W] 22.1 24.3 30.5 41.0 45.1 68.8 78.6 97.8 149.9 151.8
Regen-
erative
Resistor
Built-In
Regenera-
tive Resistor
Resistance
[
Ω ]
−−−−40 40 40 20 12 12
Capacity [W] −−−−40 40 40 60 60 60
Minimum Allowable External
Resistance [
Ω ]
40 40 40 40 40 40 40 20 12 12
Overvoltage Category III
Model SGD7S- R70A R90A 1R6A 2R8A 5R5A
Maximum Applicable Motor Capacity [kW] 0.05 0.1 0.2 0.4 0.75
Continuous Output Current [Arms] 0.66 0.91 1.6 2.8 5.5
Instantaneous Maximum Output Current [Arms] 2.1 3.2 5.9 9.3 16.9
Main Circuit
Power Supply
200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms]
*
0.81.62.45.08.7
Control Power Supply 200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Power Supply Capacity [kVA]
*
0.20.30.61.21.9
Power Loss
*
Main Circuit Power Loss [W] 5.1 7.3 13.5 24.0 43.8
Control Circuit Power Loss [W] 17 17 17 17 17
Built-in Regenerative Resistor Power Loss
[W]
−−−−8
Total Power Loss [W] 22.1 24.3 30.5 41.0 68.8
Regenerative
Resistor
Built-In Regenera-
tive Resistor
Resistance [
Ω ] −−−−40
Capacity [W] −−−−40
Minimum Allowable External Resistance [ Ω ] 40 40 40 40 40
Overvoltage Category III
