YASKAWA T1000V User Manual

B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710606 44B YASKAWA AC Drive T1000V Technical Manual 341
Parameter List
B
H3-11
<15>
Terminal A2 Gain Setting
Sets the level of the input value selected in H3-10 when 10
V (20 mA) is input at terminal A2.
-999.9 to
999.9
100.0
%
A A A 419 180
H3-12
<15>
Terminal A2 Bias Setting
Sets the level of the input value selected in H3-10 when 0
V (0 or 4 mA) is input at terminal A2.
-999.9 to
999.9
0.0% A A A 41A 180
H3-13
Analog Input Filter Time
Constant
Sets the primary delay filter time constant for terminals
A1 and A2. Used for noise filtering.
0.00 to
2.00
0.03
s
AAA 41B 180
<15> Parameter can be changed during run.
<26> The availability of certain parameters depends on the control method used.
H3 Multi-Function Analog Inputs Settings
H3-
Setting
Function Maximum Input Level Possible
Control
Mode
Pg.
V/f
OL
V
PM
0 Frequency Bias
Max output frequency (E1-04).
Same value can be set using H3-02 and H3-10.
OOO181
1 Frequency Gain 10 V = 100% O O O 181
2
Auxiliary Frequency Reference (used as a
Multi-Step Speed 2)
Maximum output frequency (E1-04) O O O 181
4 Output Voltage Bias Voltage class (200V or 400V). O – − 181
7 Overtorque/Undertorque Detection Level
Open Loop Vector: Motor rated torque
V/f Control: Drive rated current
OOO181
B PID Feedback 10 V = 100% O O O 181
C PID Set Point 10 V = 100% O O O 181
E Motor Temperature (PTC input) 10 V = 100.00% O O O 181
F Not used/Through Mode – O O O 181
10 FWD Torque Limit Motor rated torque − O − 181
11 REV Torque Limit Motor rated torque − O − 181
12 Regenerative Torque Limit Motor rated torque − O − 181
15 FWD/REV Torque Limit Motor rated torque − O − 181
16 Differential PID Feedback 10 V = 100% O O O 182
1F Not used/Through Mode – O O O 181
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
P
M
H4: Multi-Function Analog Outputs
Use H4 parameters to configure the multi-function analog output terminals.
H4-01
Multi-Function Analog
Output Terminal AM
Monitor Selection
Selects the data to be output through multi-function analog
output terminal AM.
Set the desired monitor parameter to the digits available in
U-. For example, enter “103” for U1-03.
When using this terminal in through mode or when not
using it at all, set “000” or “031”.
000 to 999
<26>
102 A A A 41D 182
H4-02
<15>
Multi-Function Analog
Output Terminal AM Gain
Sets terminal AM output gain.
Maximum output voltage is 10 V.
-999.9 to
999.9
100.0
%
SSS 41E 182
H4-03
<15>
Multi-Function Analog
Output Terminal AM Bias
Sets terminal AM output bias.
-999.9 to
999.9
0.0% A A A 41F 182
H5: MEMOBUS/Modbus Serial Communication
Use H5 Parameters to connect the drive to a MEMOBUS/Modbus network.
H5-01
<25>
Drive Node Address
Selects drive station node number (address) for
MEMOBUS/Modbus terminals R+, R-, S+, S-. Cycle
power for the setting to take effect.
0 to FFH 1F A A A 425 386
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
P
M
