A - 4 DS457 Fixed Mount Imager Integration Guide
Image Edge Sharpening 664 F1h 98h Low 7-24
Image Contrast Enhancement 666 F1h 9Ah Off 7-25
Image Rotation 665 F1h 99h 0 7-26
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 7-27
Signature Capture 93 5Dh Disable 7-28
Signature Capture Image File Format
Selection
313 F0h 39h JPEG 7-29
Signature Capture Bits per Pixel (BPP) 314 F0h 3Ah 8 BPP 7-30
Signature Capture Width 366 F4h F0h 6Eh 400 7-30
Signature Capture Height 367 F4h F0h 6Fh 100 7-31
Signature Capture JPEG Quality 421 F0h A5h 65 7-31
Video Mode Format Selector 916 F2h 94h JPEG 7-32
Video View Finder 324 F0h 44h Disable 7-32
Target Video Frame Size 328 F0h 48h 2200 bytes 7-33
Video View Finder Image Size 329 F0h 49h 1700 bytes 7-33
Video Resolution 667 F1h 9Bh 1/4 resolution 7-34
SSI Host Parameters
Select SSI Host N/A N/A N/A 8-9
Baud Rate 156 9Ch 9600 8-10
Parity 258 9Eh None 8-11
Check Parity 151 97h Disable 8-12
Software Handshaking 159 9Fh ACK/NAK 8-12
Host RTS Line State 154 9Ah Low 8-13
Decode Data Packet Format 238 EEh Send Raw Decode
Data
8-13
Host Serial Response Time-out 155 9Bh 2 sec 8-14
Host Character Time-out 239 EFh 200 msec 8-15
Multipacket Option 334 F0h 4Eh Option 1 8-16
Interpacket Delay 335 F0h 4Fh 0 ms 8-17
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
