7 - 4 DS8108 Digital Scanner Product Reference Guide

IBM Host Parameters

Port Address

Scan one of the following bar codes to select the IBM 468X/469X port.

NOTE Scanning a Port Address bar code enables the RS-485 interface on the scanner.

NOTE For a list of supported scanner functionality by communication protocol, see

Appendix F, Communication Protocol Functionality.

*None

Hand-held Scanner Emulation (Port 9B)

Non-IBM Scanner Emulation (Port 5B)

Table-top Scanner Emulation (Port 17)
