Zebra DS8108 User Manual

APPENDIX D ASCII CHARACTER
SETS
NOTE For the Keyboard Wedge Interface, Code 39 Full ASCII interprets the bar code special character ($ + % /)
preceding a Code 39 character and assigns an ASCII character value to the pair. For example, if you
enable Code 39 Full ASCII and scan +B, it transmits as b, %J as ?, and %V as @.
Scanning ABC%I outputs the keystroke equivalent of ABC >.
Table D-1 ASCII Character Set
ASCII Value
(Prefix/Suffix Value)
Full ASCII Code 39
Encode Char
Keystroke
ASCII Character
(Applies to RS-232 Only)
1000 %U CTRL 2
NUL
1001 $A CTRL A SOH
1002 $B CTRL B STX
1003 $C CTRL C ETX
1004 $D CTRL D EOT
1005 $E CTRL E ENQ
1006 $F CTRL F ACK
1007 $G CTRL G BELL
1008 $H CTRL H/BACKSPACE
1
BCKSPC
1009 $I CTRL I/HORIZONTAL TAB
1
HORIZ TAB
1010 $J CTRL J LF/NW LN
1011 $K CTRL K VT
1012 $L CTRL L FF
1013 $M CTRL M/ENTER
1
CR/ENTER
1
The keystroke in bold transmits only if you enabled Function Key Mapping on page 4-14 or page 8-8.
Otherwise, the unbold keystroke transmits.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
