Intelligent Document Capture 13 - 17
IDC Delay Time
Parameter Name: DocCap_DELAY
Parameter # 830
SSI # F2h 3Eh
This parameter only applies when IDC Operating Mode is set to Free-Form. Set the delay for capturing a
document after a trigger pull. Decoding a bar code aborts this delay.
Scan the following bar code, and then scan three bar codes from Appendix B, Numeric Bar Codes in the range of
000 to 200 decimal in units of 10 msec. The default is 000.
IDC Zoom Limit
Parameter Name: Sig_MIN_PERCENT
Parameter # 651
SSI # F1h 8Bh
This parameter only applies when IDC Operating Mode is set to Anchored. Set the minimal "zoom" percentage
value of a form for it to be considered for capture. This controls the quality of the captured form. The IDC firmware
rejects capturing a form unless the width is at least the IDC Zoom Limit percentage of the IDC Width parameter. For
example, if you set this parameter to 100 and IDC Width to 150, the form must be at least 300 pixels wide before it
is captured (each unit module is scaled to two pixels).
Set this to zero (the default) to disable all checking.
Scan the following bar code, and then scan three bar codes from Appendix B, Numeric Bar Codes in the range of
000 to 100 percent. The default is 000.
IDC Delay Time
IDC Zoom Limit
