Zebra DS8108 User Manual

3 - 8 DS8108 Digital Scanner Product Reference Guide
Technical Specifications
Table 3-2 Technical Specifications
Item Description
Physical Characteristics
Dimensions 6.6 in. H x 2.6 in. W x 4.2 in. D
16.8 cm. H x 6.6 cm. W x 10.7 cm. D
Weight
DS8108-SR/DL
DS8108-HC
5.4 oz./154 g
5.5 oz./156 g
Available Colors Twilight Black, Nova White, Healthcare White (DS8108-HC)
Power
DS8108-SR
DS8108-HC
DS8108-DL
5 VDC +/- 10% @ 470 mA (RMS typical)
5 VDC +/- 10% @ 470 mA (RMS typical)
5 VDC +/- 10% @ 470 mA (RMS typical)
Supported Host Interfaces USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard Support Supports over 90 international keyboards
FIPS Security Certification Certified Compliant with FIPS 140-2
User Indicators Direct Decode Indicator, Good Decode LEDs, Rear View LEDs,
Beeper (Adjustable Tone & Volume), Battery Indicator
Performance Characteristics
Light Source
DS8108-SR
DS8108-HC
DS8108-DL
Aiming pattern: 617 nm LED / Illumination: 660 nm LEDs
Aiming pattern: 528 nm LED/ Illumination: Warm white LEDs
Aiming pattern: 617 nm LED / Illumination: 660 nm LEDs
Illumination
DS8108-SR/DL
DS8108-HC
Two 645nm red LEDs
Two warm white LEDs
Field of View
(Horizontal x Vertical) Nominal
48° H x 37° V
Image Sensor 1,280 x 960 pixels
Minimum Print Contrast 16% minimum reflective difference
Skew Tolerance +/- 60°
Pitch Tolerance +/- 60°
Roll Tolerance 0-360°

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
