Zebra DS8108 User Manual

Keyboard Wedge Interface 8 - 5
Keystroke Delay
This is the delay in milliseconds between emulated keystrokes. Scan one of the following bar codes to increase the
delay when hosts require a slower data transmission.
Intra-keystroke Delay
Scan Enable Intra-keystroke Delay to insert an additional delay between each emulated key press and release.
This also sets Keystroke Delay to a minimum of 5 msec.
*No Delay
Medium Delay (20 msec)
Long Delay (40 msec)
Enable Intra-keystroke Delay
*Disable Intra-keystroke Delay

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
