Zebra DS8108 User Manual

15 - 2 DS8108 Digital Scanner Product Reference Guide
Driver’s License Parsing
To enable driver's license parsing on the scanner, scan the Embedded Driver's License Parsing bar code. This does
not require Zebra software (.DLL).
Scan the bar codes on the following pages in the order indicating the sequence of data fields that the scanner
outputs. See Parsing Driver’s License Data Fields (Embedded Driver's License Parsing) on page 15-3 for more
information.
*No Driver’s License Parsing
Embedded Driver’s License Parsing

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
