L - 6 DS8108 Digital Scanner Product Reference Guide

Code 11 with 2 Check Digits

Interleaved 2 of 5

MSI with 2 Check Digits

2468101275

12345678901231

NOTE MSI must be enabled to read the following bar code (see MSI on page 11-63).

123455834
