Zebra DS8108 User Manual

Symbologies 11 - 75
GS1 DataBar Security Level
Parameter # 1706
SSI # F8h 06h AAh
The scanner offers four levels of decode security for GS1 DataBar (GS1 DataBar Omnidirectional, GS1 DataBar
Limited, GS1 DataBar Expanded) bar codes.
• Security Level 0 - The scanner operates in its most aggressive state, while providing sufficient security
decoding most in-spec bar codes.
• Security Level 1 - This setting eliminates most misdecodes while maintaining reasonable aggressiveness.
• Security Level 2 - Select this option with greater bar code security requirements if Security Level 1 fails to
eliminate misdecodes.
• Security Level 3 - If you selected Security Level 2 and misdecodes still occur, select this security level to
apply the highest safety requirements.
GS1 DataBar Security Level 0
(0)
*GS1 DataBar Security Level 1
(1)
GS1 DataBar Security Level 2
(2)
GS1 DataBar Security Level 3
(3)

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
