Zebra DS8108 User Manual

Symbologies 11 - 3
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
16 10h Ignore 11-14
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
000 11-17
UPC/EAN/JAN Supplemental Redundancy 80 50h 10 11-17
Decode UPC/EAN/JAN Supplemental
AIM ID
672 F1h A0h Combined 11-18
Transmit UPC-A Check Digit 40 28h Enable 11-19
Transmit UPC-E Check Digit 41 29h Enable 11-19
Transmit UPC-E1 Check Digit 42 2Ah Enable 11-20
UPC-A Preamble 34 22h System Character 11-21
UPC-E Preamble 35 23h System Character 11-22
UPC-E1 Preamble 36 24h System Character 11-23
Convert UPC-E to A 37 25h Disable 11-24
Convert UPC-E1 to A 38 26h Disable 11-24
EAN/JAN Zero Extend 39 27h Disable 11-25
UCC Coupon Extended Code 85 55h Disable 11-25
Coupon Report 730 F1h DAh New Coupon
Format
11-26
UPC Reduced Quiet Zone 1289 F8h 05h 09h Disable 11-27
Code 128
Code 128 8 08h Enable 11-28
Set Length(s) for Code 128 209, 210 D1h, D2h Any Length 11-28
GS1-128 (formerly UCC/EAN-128) 14 0Eh Enable 11-30
ISBT 128 84 54h Enable 11-30
ISBT Concatenation 577 F1h 41h Autodiscriminate 11-31
Check ISBT Table 578 F1h 42h Enable 11-32
ISBT Concatenation Redundancy 223 DFh 10 11-32
Ignore Code 128 <FNC4> 1254 F8h 04h E6h Honor 11-33
Table 11-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
