Zebra DS8108 User Manual

11 - 6 DS8108 Digital Scanner Product Reference Guide
GS1 DataBar
GS1 DataBar Omnidirectional (formerly GS1
DataBar-14)
338 F0h 52h Enable 11-73
GS1 DataBar Limited 339 F0h 53h Enable 11-73
GS1 DataBar Expanded 340 F0h 54h Enable 11-74
Convert GS1 DataBar to UPC/EAN/JAN 397 F0h 8Dh Disable 11-74
GS1 DataBar Security Level 1706 F8h 06h AAh Level 1 11-75
GS1 DataBar Limited Margin Check 728 F1h D8h Level 3 11-76
Symbology-Specific Security Features
Redundancy Level 78 4Eh 1 11-77
Security Level 77 4Dh 1 11-79
1D Quiet Zone Level 1288 F8h 05h 08h 1 11-80
Intercharacter Gap Size 381 F0h 7Dh Normal 11-81
Composite Codes
Composite CC-C 341 F0h 55h Disable 11-82
Composite CC-A/B 342 F0h 56h Disable 11-82
Composite TLC-39 371 F0h 73h Disable 11-83
Composite Inverse 1113 F8h 04h 59h Regular Only 11-83
UPC Composite Mode 344 F0h 58h UPC Never Linked 11-84
Composite Beep Mode 398 F0h 8Eh Beep As Each Code
Type is Decoded
11-85
GS1-128 Emulation Mode for UCC/EAN
Composite Codes
427 F0h ABh Disable 11-85
2D Symbologies
PDF417 15 0Fh Enable 11-86
MicroPDF417 227 E3h Disable 11-86
Code 128 Emulation 123 7Bh Disable 11-87
Data Matrix 292 F0h 24h Enable 11-88
GS1 Data Matrix 1336 F8h 05h 38h Disable 11-88
Data Matrix Inverse 588 F1h 4Ch Inverse Autodetect 11-89
Table 11-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
