Zebra MC3300X User Manual

Accessories
132
6.
Touch Disconnect.
7. Touch eth0.
8. Touch the IP settings drop-down list and select Static.
9. In the IP address field, enter the proxy server address.
10. If required, in the Gateway field, enter a gateway address for the device.
11. If required, in the Netmask field, enter the network mask address
12. If required, in the DNS address fields, enter a Domain Name System (DNS) addresses.
13. Touch CONNECT.
14. Touch .
Establishing Ethernet Connection
1. Swipe down from the status bar to open the quick access panel and then touch .
2. Touch Ethernet.
3. Slide the Ethernet switch to the ON position.
4. Insert the device into a slot.
The icon appears in the Status bar.
5. Touch eth0 to view Ethernet connection details.
LED Indicators
There are two green LEDs on the side of the cradle. These green LEDs light and blink to indicate the data
transfer rate.
mc33-ug-en.book Page 132 Thursday, July 9, 2020 10:34 AM

Zebra MC3300X Specifications

General

Storage	32 GB
Operating Temperature	-4°F to 122°F/-20°C to 50°C
Processor	Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System	Android 11
RAM	4 GB
Display Size	4.0 inches
Display Resolution	480 x 800 pixels
Connectivity	Wi-Fi, Bluetooth
Camera	13 MP rear
Drop Specification	Multiple 6 ft./1.8 m drops to concrete across the operating temperature range
Sealing	IP65
Touch Panel	Capacitive
Scanning	1D/2D barcode scanning
Battery Type	Li-Ion
