Data Capture
88
Figure 40 Bluetooth Pairing Utility
2. Using the RS5100/RS6000/RS507/RS507X, scan the barcode on the screen.
The RS5100/RS6000/RS507/RS507X emits a string of high/low/high/low beeps. The Scan LED flashes
green indicating that the RS5100/RS6000/RS507/RS507X is attempting to establish connection with
the device. When connection is established, the Scan LED turns off and the
RS5100/RS6000/RS507/RS507X emits one string of low/high beeps.
A notification appears on the Notification panel and the icon appears in the Status bar.
Pairing Using Bluetooth Human Interface Device
To pair the RS5100/RS6000/RS507/RS507X with the device using Human Interface Device (HID):
1. Ensure that Bluetooth is enabled on both devices.
2. Ensure that the Bluetooth device to discover is in discoverable mode.
3. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
4. Place the RS5100/RS6000/RS507/RS507X in HID mode. If the RS5100/RS6000/RS507/RS507X is
already in HID mode, skip to step 5.
a. Remove the battery from the RS5100/RS6000/RS507/RS507X.
b. Press and hold the Restore key.
c. Install the battery onto the RS5100/RS6000/RS507/RS507X.
d. Keep holding the Restore key for about five seconds until a chirp is heard and the Scan LEDs flash
green.
e. Scan the barcode below to place the RS5100/RS6000/RS507/RS507X in HID mode.
mc33-ug-en.book Page 88 Thursday, July 9, 2020 10:34 AM
