Zebra MC3300X User Manual

Technical Specifications
193
1-Slot USB Charge Cradle with Spare Battery Charger Technical Specifications
Table 38 I/O Connector Pin-Outs
Pin Signal Name Description
1 Ground Ground pin connected to the Cradle or USB Charge Cable ground.
2 USB ID Identification signal for USI OTG communication (USB ID) which
determines USB mode (host or device).
3 POWER_IN_CON
(9V/1.5A or
5V/2Amax)
DC Power supply from the Cradle.
4 USB PWR Power supply from USB Charging Cable.
5 USB D- USB OTG data signal negative.
6 USB D+ USB OTG data signal positive.
7 GND Ground pin connected to the Cradle or USB Charge Cable ground.
Table 39 1-Slot USB Charge Cradle with Spare Battery Charger Technical Specifications
Item Description
Dimensions Height: 104.5 mm (4.11 in.)
Width: 99.1 mm (3.90 in.)
Depth: 155.5 mm (6.12 in.)
Weight 376 g (13.26 oz)
Input Voltage 12 VDC
Power Consumption 17 watts
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity 10% to 95% non-condensing
Drop 75 cm (30 in.) to concrete; 2 drops/side for a total of 12 drops at
room temperature.
Electrostatic Discharge (ESD) +/- 20 kV air
+/- 10 kV contact
+/- 10 kV indirect discharge
mc33-ug-en.book Page 193 Thursday, July 9, 2020 10:34 AM
