Accessories
158
Replacement Hand Strap for MC3300x-G
To install the hand strap:
1. Thread the lanyard loop through the opening near the base of the trigger handle.
Figure 70 Insert Loop Through Handle Slot
2. Insert the top end of the hand strap through the loop.
Figure 71 Thread Hand Strap Through Loop
3. Thread the hand strap through the lanyard.
4. Pull the hand strap through the loop.
5. Thread the end of the hand strap with the tab through the slot on the bottom of the MC3300x-G.
mc33-ug-en.book Page 158 Thursday, July 9, 2020 10:34 AM
