Zebra MC93 Series Product Reference Guide

Accessories
113
Configuring Ethernet Proxy Settings
The MC93XX includes Ethernet cradle drivers. After inserting the device, configure the Ethernet
connection:
1. Swipe down from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet > Ethernet.
3. Slide the switch to the ON position.
4. Place the device into the Ethernet cradle slot.
5. Touch and hold eth0 until the menu appears.
6. Touch Modify Proxy.
7. Touch the Proxy drop-down list and select Manual.
8. In the Proxy hostname field, enter the proxy server address.
9. In the Proxy port field, enter the proxy server port number.
NOTE: When entering proxy addresses in the Bypass proxy for field, do not use spaces or carriage returns
between addresses.
10. In the Bypass proxy for text box, enter addresses for web sites that do not require to go through the
proxy server. Use the separator comma “,” between addresses.
11. Touch MODIFY.
12. Touch the Home button.
Configuring Ethernet Static IP Address
The MC93XX includes Ethernet cradle drivers. After inserting the device, configure the Ethernet
connection:
1. Swipe down from the status bar to open the quick access panel and then touch .
2. Touch Network & Internet > Ethernet.

Zebra MC93 Series Specifications

General

Operating Temperature	-4°F to 122°F/-20°C to 50°C
Processor	Qualcomm Snapdragon 660 octa-core, 2.2 GHz
Operating System	Android 11
RAM	4 GB
Storage	32 GB Flash
Battery	7000 mAh
Connectivity	USB 2.0
Camera	13 MP rear camera
Drop Specification	Multiple 8 ft. / 2.4 m drops to concrete per MIL-STD 810G across operating temperature range
Sealing	IP65
Touch Panel	Capacitive Corning Gorilla Glass
Keypad Options	Numeric, Function Numeric, Alpha-Numeric
Scanning	1D/2D
Wireless LAN	802.11 a/b/g/n/ac
Audio	Speaker, microphone
Display	4.3 in. WVGA (800 x 480), color TFT-LCD with backlight
