ZEISS OPERATION Axio Imager 2
Operating the motorized microscope via the touchscreen of the TFT display
104 430000-7544-001 01/2016
4.8.1 Screen layout
The control elements and information displays are
contained on various, thematically organized
pages. Basically, each page on the TFT display is
divided into the following main areas (Fig. 91).
4.8.1.1 Navigation button bar
The navigation button bar down the left side of
the screen contains buttons for activating all
pages. Which buttons are available depends on the
page currently being displayed. However, the
following buttons are accessible on all pages:
− Home Activates the start page
− Favorites Calls up the favorites page
− Display Activates the display page
4.8.1.2 Status line
The status line on the lower edge of the screen
provides information on the current settings of the:
objective nosepiece,
reflector turret,
condenser,
lamp voltage or intensity,
switching status of the internal power supply.
Pop-up windows are not shown in the status line
Fig. 91 Main areas of the TFT display
Control area
N
a
v
i
g
a
t
i
o
n
b
u
t
t
o
n
b
a
r
Navigation status bar
