Capturing large overviews (tiles or MosaiX images) on Axio Imager 2
01/2016 430000-7544-001 155
Settings of the orientation of the camera image in the live image window and the axis orientation in
software for capturing large overview images (mosaics) in the Axio Imager 2:
position
Camera orientation in software x axis y axis
Eyepiece "p"
Stage "d"
Camera on top port of
inverse tube
"p"
WSB05 / WSB08 180° rotation Inverted ./.
SMC 2009 180° rotation Inverted Inverted
CAN bus 180° rotation Inverted ./.
Ludl MAC 6000 180° rotation Inverted ./.
Camera on
side port
"q"
WSB05 / WSB08 Horizontal reflection Inverted ./.
SMC 2009 Vertical reflection Inverted Inverted
CAN bus Horizontal reflection Inverted ./.
Ludl MAC 6000 Horizontal reflection Inverted ./.
Camera on top port
upright tube
"p"
WSB05 / WSB08 180° rotation Inverted ./.
SMC 2009 180° rotation Inverted Inverted
CAN bus 180° rotation Inverted ./.
Ludl MAC 6000 180° rotation Inverted ./.
An Axiocam was used for this installation. The camera was oriented with the label pointing towards the
user and the cable to the rear.
Now you can use the Tiles&Positions module of e.g. the ZEN software to acquire huge overview images.
