Zmorph FAB - Page 71

Product Manual - ZMORPH FAB back to table of content >>
71
If after the second round of calibration the user still decides that
none of the lines are accurate, the machine will show a warning
screen and advise to repeat the automatic calibration process or to
perform the manual calibration.
Calibration
result inaccurate
REPEAT
MANUAL
BACK
NOTE
NOTE
If meeting calibration issues or autocalibration doesn’t work, please contact Technical Support.
Dual Extruder Toolhead
Before performing the automatic calibration make sure the worktable is clean and prepared.
See the toolhead changing process before mounting the Dual Extruder Toolhead on the machine.
During the automatic calibration process the printer is heating up.
Connect the LEFT cable to
the LEFT frame socket and
RIGHT cable to the RIGHT
frame socket.
Connect the extruder ‘A’ cable
to the ‘A’ plug and the ‘B’
cable to the ‘B’ plug on the X
carriage.
Choose ‘MAINTENANCE’.
3D printing workow
NEW JOB MAINTENANCE
