Chapter 6 Access Point Mode
EMG2306-R10A User’s Guide
35
Table 11 Status Screen: Router Mode
LABEL DESCRIPTION
Device Information
Host Name This is the device’s host name.
Model Number This is the device’s model number.
Firmware Version This is the firmware version.
Sys OP Mode This shows the device mode to which the EMG2306-R10A is set.
LAN Information
- MAC Address This shows the LAN Ethernet adapter MAC Address of your device.
- IP Address This shows the LAN port’s IP address.
- IP Subnet Mask This shows the LAN port’s subnet mask.
- DHCP This shows the LAN port’s DHCP role - Server or Disable.
WLAN Information
- WLAN OP Mode This shows the device mode to which the EMG2306-R10A’s wireless LAN is set.
- MAC Address This shows the wireless adapter MAC Address of your device.
- SSID This shows a descriptive name used to identify the EMG2306-R10A in the wireless LAN.
- Channel This shows the channel number which you select manually.
- Security This shows the level of wireless security the EMG2306-R10A is using.
System Status
Item This column shows the type of data the EMG2306-R10A is recording.
Data This column shows the actual data recorded by the EMG2306-R10A.
System Up Time This is the total time the EMG2306-R10A has been on.
Current Date/Time This field displays your EMG2306-R10A’s present date and time.
System Resource
-CPU Usage This displays what percentage of the EMG2306-R10A’s processing ability is currently used.
When this percentage is close to 100%, the EMG2306-R10A is running at full load, and the
throughput is not going to improve anymore. If you want some applications to have more
throughput, you should turn off other applications (for example, using bandwidth
management.)
- Memory Usage This shows what percentage of the heap memory the EMG2306-R10A is using.
Interface Status
Interface This displays the EMG2306-R10A port types. The port types are: WAN, LAN and WLAN.
Status For the LAN and WAN ports, this field displays Down (line is down) or Up (line is up or
connected).
For the WLAN, it displays Up when the WLAN is enabled or Down when the WLAN is
disabled.
Rate For the LAN ports, this displays the port speed and duplex setting or N/A when the line is
disconnected.
For the WAN port, it displays the port speed and duplex setting if you’re using Ethernet
encapsulation. This field displays N/A when the line is disconnected.
For the WLAN, it displays the maximum transmission rate when the WLAN is enabled and N/
A when the WLAN is disabled.
LAN1 This shows the LAN1 status and data transfer rate.
LAN2 This shows the LAN2 status and data transfer rate.
