Section 2 Getting Started Accessing Displays
3BUR002418-600 A 29
Availability of Displays as Indicated by Server Status
The top right corner of each MOD display has one or two (redundancy) indicators
that show the server status between the client/server and the server/controller. These
indicators show the status conditions as described in Table 2. An overview display
with multiple controllers will not go yellow unless all nodes are down.
MOD_BUM MOD300 Message,
MOD 300 System Status
MOD_CONSOLE,
MOD_ADVANT_D2D,
MOD_DCN_DCN,
MOD_GENERICD
MOD300 Multibus,
MOD300 Message,
MOD300 System Performance,
MOD 300 System Status
MOD_ENV_AREA MOD300 Area Status, MOD300 Area Graphic,
MOD300 Area Alarm
MOD_ENV_GROUP MOD300 Group Status, MOD300 Group Graphic,
MOD300 Group Alarm, MOD300 Group Trend
Table 2. Server Status Indicators
Condition Indication Description
OK Green Connection between client/server is good.
Failed Red A connection was made but is not working.
Not Connected White No connection made between client/server.
Trying Blue Attempting a connection between client/server.
Node Down Yellow The server/controller connection has failed. The
controller node may be down.
Table 1. MOD 300 Objects and Associated Aspects (Continued)
MOD 300 Objects Associated Aspects
