AI830 Appendix A Runtime Templates
290 3BUR002418-600 A
FILTER 01 through 08
Enter the lowpass filter time constant (in 10msec units) for each channel. Filter
times shorter than the update time are not usable. Update time can be calculated as:
T
Update
= 160ms + (n * 80ms) n = number of active channels 1...8
Therefore the T
Update
Range = 240ms to 800ms
The default value is 10 (100msec).
The possible range is:
10 to 65535.
LABEL
Enter a characteristic name to identify the AI830 Module of the station. The name
may contain up to 20 characters.
POSITION
Enter a number from 1 to 12 representing the position of the I/O module relative to
the FCI. The I/O module directly next to the FCI is number 1.
Default value is 1.
POWER LINE FREQUENCY
Enter the power line frequency to filter out (notch) the signal.
The valid values are:
16, 50, and 60.
The default value is 60.
RANGE 01 through 08
The possible ranges are:
-80..80 C, -112..176 F
If positions are to be used for spare MTUs, the spares must be in place so the rest
of the I/O modules are numbered correctly. The spare MTU will use a position
number when it is on the ModuleBus.
