110 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
Configuring limit monitoring
Menu path
MENU → Configure → Component-specific → Limit Values →
Select Limit Monitor → ...
Selection
All available limit value monitors are shown.
Procedure
Parameter Explanation Action
Direction
< = Alarm when falling below the limit or
> = Alarm when exceeding the limit
Select
Threshold
in physical units Set
Hysteresis
in physical units Set
Standard configuration
As a rule, limit value monitoring for those components to be measured by
the analyzer system is factory-set. This requires that there be enough digital
outputs on the I/O modules to handle the number of sample components.
Note: Limit value monitors are factory-set or user-configured Limit Monitor
function blocks. The Technical Information "Function blocks – Descriptions
and configuration" contains complete information on the individual function
blocks.
