ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 113
Changing module name
Menu path
MENU → Configure → Component-specific → Module Name
Module name
The module name is shown in the display next to the module type. Here you
can enter a name relating to the measuring point, for example.
Monolingual or bilingual
The module name can be entered independent of the language of the user
interface (see page 115) or separately for both languages.
Text length
The length of the text for the module name is limited to 24 characters for a
monolingual entry, and limited to two times 10 characters for a bilingual
entry.
Entering the module name
When entering the module name, use the same procedure as entering text
(see page 58).
NOTICE
The changed module name is shown in the display after switching to meas-
uring mode.
If the module name appears next to or under the module type depends on
the configured size for displaying the measured quantity (see page 129).
