132 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
Page overview
Page overview
Parameter
Parameter Explanation
No.
Page number and status ("On" or "Off")
Name
Name of the page
Assignment
Page assignment
Type
System: Pages configured by system with standard layout
User: Page configured by the user
Page overview softkeys
The page overview softkeys and keys have the following functions:
The operator toggles the selected screen page on or off with the PAGE
ON/OFF softkey.
The NEW softkey starts the configuration of a new (user) page
(see page 134).
The DELETE softkey deletes the page selected by the user.
Only empty "user" pages can be deleted.
The ENTER softkey allows the user to input text to change the name of the
selected page.
The Back key returns the user to the display overview (see page 131).
PAGE
ON/OFF
NEW
DELETE
ENTER
Back
To Next Page
