ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 161
Replacing wearing parts
Before executing maintenance work on the analyzer system, the mainte-
nance control must be activated in the control display in order to set the
maintenance mode status signal.
Furthermore, the gas flow control in the control display must either be set to
zero gas local (zero air inlet directly on the measuring cell) or zero gas probe
(zero air inlet via probe) in order to avoid any contact with the measuring
gas.
After completing the maintenance work, the maintenance control and the
gas flow control must be reset.
For work on hot device parts, the temperature may drop and lead to a tem-
perature error of the system and, where applicable, to the activation of
emergency purging.
After completing the maintenance work, it must be waited until the temper-
ature error is no longer active; where applicable, emergency purging needs
to be deactivated.
Replacing wearing parts
Wearing parts Replacement cycle
Filter on the gas sampling probe
(see page 162)
At least every 12 months, depending on
the dust content of the measuring gas
Sample gas filter in the ASP block
(see page 164)
At least every 12 months, depending on
the dust content of the measuring gas
Filter in the compressed air main
controller (see page 166)
Every 12 months
Filter in the measuring gas pressure
control (see page 167)
At least every 12 months, depending on
the dust content in the ambient air
Filter cells in the air purifier
(see page 168)
Approx. every 3 years
Filter pad in the fan (see page 169) At least every 12 months, depending on
the dust content in the ambient air
Battery on the system controller
(see page 170)
Approx. every 4 years
Pressure equalization screws in the
top of the cabinet (see page 171)
Every 12 months
Spare parts information
Information on spare parts can be found on the Internet in "ABB Business
Online" at https://online.abb.com/.
NOTICE Only genuine ABB spare parts and consumables may be used!
