92
ACF5000
FTIR ANALYZER SYSTEM
|
OI/ACF50
00-EN REV. A
Adjustment: Operation
Carrying out manual reference
Creating manual reference
Function
A manual reference can be created for the FTIR spectrometer.
First,
Menu
→
Service/Test
→
System
→
Manual gas path
must be set
to apply zero air either locally
or via sampling (see page 152).
