ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 31
Material required for the installation (not supplied)
Gas sampling
Wall tube with mounting flange (DN 65, PN 6, facing type A to DIN EN 1092-1)
Gas lines
Instrument air 1 tube or compressed-air hose, O.D. 8 mm or ⅜ in. (with pressure regulator
and shut-off fitting)
Combustion gas for the FID 1 extremely clean (hydrocarbon-free) stainless steel tube (SS316), O.D. 6 mm
(ABB item no. 0017400, length = 6 m) or ¼ in.
1 two-stage cylinder pressure reducer (designed for high-purity gases) with
flow restriction
Test gas for FTIR 1 PTFE tube 4/6x1 mm or ⅙ in./¼ in.
Test gas O
2
measurement 1 PTFE tube 4/6x1 mm or ⅙ in./¼ in.
Test gases for VOC meas-
urement
2 PTFE tubes 4/6x1 mm or ⅙ in./¼ in.
Test gases for drift check 3 PTFE tubes 4/6x1 mm or ⅙ in./¼ in.
Purge gas for sampling 1 PTFE tube 4/6x1 mm or ⅙ in./¼ in., length about the same as the sample
gas line
Waste gas 1 hose, O.D. 12 mm or ½ in.
Pressure reducer for high-purity gases
Power supply lines
Power supply 5 x 6 mm
2
in compliance with DIN EN 61010-1 or 5 x AWG8
UPS (option) 3 x 2.5 mm
2
or 3 x AWG14
Connecting cables for the connections from the analyzer cabinet to the heated gas sampling
probe, filter unit, and sample gas line (possibly in temperature-resistant
design; take the power consumption of these components into account)
 Probe tube type 42: 3 x 1.5 mm
2
or 3 x AWG16
 Filter device PFE3: 3 x 1.5 mm
2
or 3 x AWG16
 Backflush for filter device PFE3: 8 x 1.5 mm
2
or 8 x AWG16
 Sample gas line TBL01 1-phase: 3 x 2.5 mm
2
or 3 x AWG14
 Sample gas line TBL01 3-phase: 5 x 2.5 mm
2
or 5 x AWG14
Grounding cable ≥ 10 mm
2
or AWG6
NOTICE When selecting the cable material, observe the applicable national safety
requirements for installing and operating electrical equipment.
