32 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
Signal lines
Analog outputs Shielded cables for the analog outputs (current outputs):
2 x 0.5 mm
2
or 2 x AWG20 per analog output
Analog inputs Shielded cables for the analog inputs (current inputs with the option
"external analog inputs"):
2 x 0.5 mm
2
or 2 x AWG20 per analog input
Digital outputs Cables for the digital outputs:
5 x 0.5 mm
2
or 5 x AWG20 per group of 4 digital outputs
Digital inputs Cables for the digital inputs (with the option "external digital inputs"):
2 x 0.5 mm
2
or 2 x AWG20 per digital input
Data lines Cables for the data lines (Modbus, PROFIBUS, Ethernet), possibly fiber-optic
cables for longer transmission distances.
On the right side wall of the analyzer cabinet, connectors for the direct con-
nection of assembled data cables can be found (Sub-D 9-pin or RJ45 or M12
panel feed-through 5-pin or 8-pin).
Resistance thermometer Cables for the Pt 100 resistance thermometers in the heated components;
3 x 0.75 mm
2
or 3 x AWG20 per temperature sensor
NOTICE When selecting the cable material, observe the applicable national safety
requirements for installing and operating electrical equipment.
Assembly
Bolts and nuts for fastening the analyzer cabinet to the floor (see "Location
diagram in the system documentation)
