ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 85
Configuring manual adjustment
NOTICE
The descriptions in this section refer to the adjustment of the analyzer
modules FID and oxygen sensor.
Menu path
MENU → Configure → Adjustment Data → Manual Adj. → ...
Test gas concentration
The zero and span test gas concentrations to be used as set points for
manual adjustment need to be set for the selected sample component and
measuring range.
Adjustment method
The adjustment method (see page 72) is to be set for the manual adjust-
ment.
With … … are to be selected:
Common adjustment the measured components and or the selected
measured component the measuring ranges for
the start and end point adjustment.
Substitute gas adjustment the (substitute gas) components for the start
and end point adjustment as well as for the
component of the measuring range selected.
NOTICE
The settings of the components and measuring ranges apply both for the
manual and for the automatic and externally controlled adjustment.
