30 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
Scope of supply and delivery
Standard scope of supply and delivery
Qty. Description
1 Analyzer cabinet (all components installed)
1 set system documentation
Included with delivery if ordered
Qty. Description
1 Type 40 (unheated) or Type 42 (heated) gas sampling probe
1 Type PFE2 filter unit, heated
1 Type TBL01 sample gas line, heated
1 System transformer, 100 V to 230 V (option)
2nd measuring location option
Qty. Description
1 Type 40 (unheated) or Type 42 (heated) gas sampling probe
1 Type PFE2 filter unit, heated
1 Type TBL01 sample gas line, heated
1 Heated selector valve
1 Heated sample gas line to analyzer cabinet
1 Electrical distribution cabinet for 2nd measuring location
"Hydrogen monitoring of the analyzer cabinet" option
Qty. Description
1 Gas warning center Unipoint
1 Contactor for disconnecting the power supply to the analyzer
cabinet
1 Contactor for disconnecting the UPS if the system is prepared
for a UPS
1 Unipoint Multilingual Manual CD
1 Sensepoint Manuals CD
NOTICE The gas sensor and the H
2
safety valve are installed in the analyzer
cabinet.
