ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 187

Status messages FTIR

List layout

The status message list contains the following information:

No. The status message number appears in the menu line display

A x = Status message sets the "Error" individual status

W x = Status message sets the "Maintenance request" individual

status

F x = Status message sets the "Maintenance mode" individual status

S x = Status message sets the overall status

Text Short and long text of the status message

Reaction/

Comment

Explanations and corrective measures in case of status messages

NOTICE When status messages occur with numbers > 2000 that are not stated in the

list, service must be notified.

Status messages 2013, 2014, 2015, 2025, 2026, 2027, 2028, 2029, 2030, 2031,

2032 are for information only.

Status messages

No. A

F S Short and long text Reaction/Comment

424 x x Temperature Problem

The temperature value of the controller and

the redundant temperature measurement

differ.

Check temperatures of the measuring

gas collection components:

Menu → Diagnosis/Information →

Module-specific → Raw measured values

auxiliary values → SGIn

Where applicable, notify service.

425 x x Excess temperature

The temperature value of the controller ex-

ceeds the maximum limit value.

Check temperatures:

Menu → Diagnosis/Information →

Module-specific → Controller measured

values

Notify service in the event of constant or

increasing values.

426 x x Emergency stop

The temperature controller was deactivated

due to a malfunction. To activate, rectify fault

and confirm this message.

Check temperatures:

Menu → Diagnosis/Information →

Module-specific → Controller measured

values

After cooling down to T < 190°C, confirm

message to reactivate the heating.

Notify service if this occurs again.

2001 x WARNINGLOW

Alarm state: WARNINGLOW
