188 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
No. A
W
F S Short and long text Reaction/Comment
2006 x ALARMLOW
Alarm state: ALARMLOW
Check measuring gas concentration.
Notify service.
2007 x ALARMHIGH
Alarm state: ALARMHIGH
Check measuring gas concentration.
Notify service.
2008 x ALARM
Alarm state: ALARM
Check measuring gas concentration.
Notify service.
2009 x FAULT
Alarm state: FAULT
Check measuring gas concentration.
Notify service.
2218 InstrEboxTmpHm
Instrument health error: EBOX Tempera-
ture(HM) The health monitoring reports a
problem with the EBOX temperature
Check internal and external cabinet
temperatures. Check function of the
ventilator or cooling device.
Notify service.
2219 InstrBMXSTempHm
Instrument health error: BMXS Tempera-
ture(HM) The health monitoring reports a
problem with the board temperature of the
BMXS
Check internal and external cabinet
temperatures. Check function of the
ventilator or cooling device.
Notify service.
2222 InstrDetTempHm
Instrument health error: Detector Temp. (HM)
The health monitoring reports a problem with
the detector temperature
Check internal and external cabinet
temperatures. Check function of the
ventilator or cooling device.
Notify service.
2226 InstrCoAddFwdHm
Instrument health error: CoAdd. Rej. Fwd (HM)
CoAdd reports a problem with the forwards
movement. Please check for vibrations.
See message text
2227 InstrCoAddRevHm
Instrument health error: CoAdd. Rej. Rev (HM)
CoAdd reports a problem in reverse move-
ment Please check for vibrations
See message text
2500 x Ref. Temp. >>
The analyzer temperature is outside the de-
fined range for the last zero point reference.
With a deactivated automatic reaction to
temperature violation, enter manual
reference.
With an activated automatic reaction to
temperature violation, the message is
for information purposes.
Web page → ACF5000 settings → Tem-
perature range check
2501 Auto ref. Start
Automatic zero point reference started.
For information
2502 Auto ref. End
Automatic zero point reference ended.
For information
2503 Auto ref. Cancel
Automatic zero point reference canceled ex-
ternally.
For information
2504 x Auto ref. In progress
Automatic zero point reference in progress.
For information
2505 x Auto ref. Errors
Automatic zero point reference failed.
Enter manual reference
Notify service if this occurs again.
2506 x x High alarm
High alarm triggered by the components:
For information
2507 AAC start
Automatic Adjustment Check started.
For information
