DescriptionCode
Voltage range
525…690 V AC. This is indicated in the type designation label as typical input voltage levels
(3~ 525/600/690 V AC)
7
Option codes (plus codes)
Supply connection
12-pulse supply connectionA004
24-pulse supply connectionA006
60 Hz supply frequencyA013
Degree of protection
IP42 (UL Type 1)B054
IP54 (UL Type 12)B055
Construction
Marine construction. See section Descriptions of options (page 40).
C121
ACS880-1007LC cooling unit as part of line-upC138
ACS880-1007LC cooling unit (separate from line-up)C139
Single-pump cooling unitC140
Redundant (twin-pump) cooling unitC141
Pipe connection through bottomC142
Pipe connection on leftC144
External cooling circuit suitable for sea waterC146
Plinth height 100 mm. See section Descriptions of options (page 40).
C164
Door hinges on leftC176
Plinth height 200 mm. See section Descriptions of options (page 40).
C179
Marine product certification issued by DNV GLC205
Marine product certification issued by the American Bureau of Shipping (ABS)C206
Marine product certification issued by Lloyd's Register (LR)C207
Marine product certification issued by Bureau VeritasC209
Cooling unit pumps can run simultaneouslyC213
Marine product certification issued by China Classification Society (CCS)C228
Marine product certification issued by Russian Maritime Register of Shipping (RS)C229
2-way valve in a dedicated cubicleC242
Resistor braking
Brake choppersD150
Brake resistorsD151
Filters
du/dt filteringE205
EMC filter for 2nd environment TN (grounded) or IT (ungrounded) system, category C3E210
Switching and grounding
Output grounding terminalsF271
Internal charging circuitF272
46 Operation principle and hardware description
