ABB ACS880-07CLC

DescriptionCode
Cabinet equipment
Cabinet and module heating elements (external supply). See section Descriptions of op-
tions (page 40).
G300
Cabinet lighting. See section Descriptions of options (page 40).
G301
Output for motor space heater (external supply)G313
Halogen-free wiring and materialsG330
Additional wire markings. See section Descriptions of options (page 40).
G338
G339
G340
G341
G342
Cabling
Supply cabling direction downH350
Motor cabling direction downH352
Cable conduit entry (US/UK). See section Descriptions of options (page 40).
H358
Common motor terminal cubicle. See section Descriptions of options (page 40).
H359
Gland plate out of 3 mm thick aluminum, blindH364
Common output terminals (for inverter modules mounted in the same cubicle). See section Descrip-
tions of options (page 40).
H366
Control cable entry through floor of cabinetH367
Control panel
Control panelJ400
Fieldbus adapters, diverse communication options
Panel bus (control of several units from one control panel)K450
FDNA-01 DeviceNet™ adapter moduleK451
FPBA-01 PROFIBUS DP adapter moduleK454
FCAN-01 CANopen adapter moduleK457
FSCA-01 RS-485 (Modbus/RTU) adapter moduleK458
FCNA-01 ControlNet™ adapter moduleK462
FECA-01 EtherCat adapter moduleK469
FEPL-02 EtherPOWERLINK adapter moduleK470
FENA-11 Ethernet adapter module for EtherNet/IP™, Modbus TCP and PROFINET IO protocolsK473
FENA-21 Ethernet adapter module for EtherNet/IP™, Modbus TCP and PROFINET IO protocols,
2-port
K475
I/O extensions and feedback interfaces
FIO-11 analog I/O extension moduleL500
FIO-01 digital I/O extension moduleL501
FEN-31 HTL incremental encoder interface moduleL502
FDCO-01 optical DDCS communication adapter moduleL503
Additional I/O terminal block. See section Descriptions of options (page 40).
L504
FDCO-02 optical DDCS communication adapter moduleL508
FAIO-01 analog I/O extension moduleL525
FDIO-01 digital I/O extension moduleL526
Operation principle and hardware description 47
