$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ 0HPRU\&DOFXODWLRQ
3BSE 002 415R701 Rev A 3-37
PIDCON Excluding I/O signals x 1.50
PIDCONA Excluding I/O signals x 8.5
MANSTN Excluding I/O signals x 0.80
RATIOSTN Excluding I/O signals x 1.00
GENCON Excluding I/O signals x 0.50
GENBIN Excluding I/O signals x 0.50
GENUSD Excluding I/O signals x 0.50
VALVECON Excluding I/O signals x 0.60
MOTCON Excluding I/O signals x 0.80
GROUP Excluding I/O signals
(1)
1 x 3.00
SEQ Excluding I/O signals x 1.00
DAT No. of DB elements x 0.02
TEXT No. of DB elements x 0.14
Table handling No. of tables
(2)
x 4.90
MasterView 320 Basic requirements for QC07-LOS41 1 x 240.00
No. of displays
(3)
x 2.00
No. of MasterView 320 with event lists
(4)
x 9.00
AS 500 Series
operator station
and IMS Station or
MV800/1
Basic requirement for QC07-OPF41 1 x 799.00
No. of trend data storage logs
(5)
x 12.00
Group alarm, No. of group objects
No. of group members
x 0.13
x 0.09
MasterBatch 200/1 Basic requirement for QC07-BAT41 1 x 418.00
No. of SECCONx1.7+OPCONx6.0+
TANKCONx1.8
x 1.00
No. of processes
(6)
x 25.00
PROFIBUS DP No. of PROFIBUSES x 1.20
Number of PROFIBUS slaves x 0.80
7DEOH &DOFXODWLRQRI5$0UHTXLUHPHQW&RQWLQXHG
2EMHFWW\SH 5HPDUN 7RWDO
)DFWRU
NE\WHV
5$0UHT
