&KDSWHU &RQILJXUDWLRQ$SS OLFDWLRQ%XLOGLQJ
3-38 3BSE 002 415R701 Rev A
LONWORKS
Network
No. of LONWORKS Communication
modules (CI572/CI573)
x 65
No. of LONWORKS devices x 0.2
No. of LONWORKS variables
(input and outputs)
x0.06
No. of LONWORKS multiple network
variable
x 0.33
No. of LONWORKS Event Treat x 0.14
No. of MasterBus
300/300E,
RCOM/RCOM+,
GCOM and
MultiVendor Inter-
face
x 8.00
User Defined
PC elements
Basic requirements for QC07-UDP41 1 x 132.00
Storage of user defined PC elements
(7)
1 x 150.00
Space for storage of User Diskette contents
(7)
x 100.00
Basic requirements for QC07-LIB41 1 x 32.00
Basic requirements for QC07-LIB42 1 x 479.00
Basic requirements for QC07-FUZ41 1 x 40.00
Basic requirements for QC07-COM41 1 x 33.00
Basic requirements for QC07-BAS41 1 x2207.00
Spare RAM area
(8)
1 x 40.00 40.00
$SSUR[LPDWLYHWRWDO5$0UHTXLUHPHQWLQNE\WHV

(1) The figures are calculated for 8 steps (MOTCON not included).
(2) The figures are calculated for 1 table with 10 rows and 100 values per row.
(3) The figures are calculated for 40 text strings with 20 characters and 30 dynamic values.
(4) The figures apply to 100 events per list.
(5) The figures are calculated for 1 log with 10 variables, each with 240 stored values.
Each value takes approximately 5 byte.
(6) The figures are calculated for 50 storage vessels, 4 sections and 20 operations with 6 recipe variables each.
(7) This is a recommended starting value. Adjustment of this figure might be necessary to do when the real need is known.
(8) Recommended value for most systems.
(9) Must be less than the RAM size of the processor module (8 or 16 Mbyte).
7DEOH &DOFXODWLRQRI5$0UHTXLUHPHQW&RQWLQXHG
2EMHFWW\SH 5HPDUN 7RWDO
)DFWRU
NE\WHV
5$0UHT
